Statistics of station Sonneberg

Here you can find statistics of the TOA lightning detection station Sonneberg.

  • Firmware: 1.7
  • Controller: 10.4
  • Amplifier: 12.3
  • Antenna 1+2: Ferrite rod, length=200mm
  • Website: www.sumbarg.de

General statistics of the last hour

  • Station active: yes
  • Last update: 9.0 minutes ago
  • Last detected stroke: 2024-12-22 02:04:08
  • Strokes: 0
  • Signals: 141
  • Locating ratio: 0.0%
  • Stroke ratio: 0.0%
  • Strokes station min participants: 0 (0.0%)

GPS

Some information about the GPS receiver, which is used for receiving the exact time an position. If known, the antenna bearings are also displayed (red, green).

  • Mean coordinates: 50.364069° / 11.153776° (±2.1m)
  • Last time without GPS: 2018-03-16 19:55:18

Stroke count

Here you can see the whole stroke count per hours detected by the lightning network, the count of detected strokes/h of the station Sonneberg and the mean stroke count for all stations

Graphs: Stroke statistics

Signal count

The count of received signals per hour of the station Sonneberg and also mean value of all stations.

Graphs: Signal statistics

Ratios

Stroke and locating ratios are important parameters for the correct adjustment of the station. Calculations:
locating ratio = (detected strokes of the station) / (signals of the station)
stroke ratio = (detected strokes of the station) / (network stroke count)

Graphs: Locating and stroke ratios

Stroke ratio by distance

Overview about the own locating ratio over distance from stations. Whole stroke count over distance is also visible.

Graphs: Stroke ratio by distance

Stroke ratio by bearing

Own locating ratio over the geographic direction. For better comparision, there is also the whole stroke count visible.

Graphs: Stroke ratio by bearing
